Description
Functions
BROADBAND AND NARROWBAND CONVERGENCE
Enables the collaboration of multiple communication modes including broadband and narrowband networks as well as public and private networks in multiple scenarios.
FRIENDLY DESIGN
5-inch industrial-grade HD touch screen adopts the third-generation glass of Corning Gorilla Glass.
LOUD AND CLEAR VOICE QUALITY
Built-in 1W(up to 2.5W)speaker provides loud and clear audio quality for versatile voice service.
OPEN PLATFORM PROVIDING INFINITIES
Multiple applications can run on it. Open API allows third party developing customized applications.
RUGGED AND COMPACT DESIGN
With exquisite structural technology, IP68, military standard(MIL-STS-810G) and 1.2m drop-proof-design.
MULTIPLE PROTECTION MECHANISMS ENSURING SECURITY
Communication security: The TF card slot design is used for communication and hardware encryption. Application security: The radio uses professional MDM management software that can remotely control 100% terminal applications. All applications must complete signature authentication before uploaded to MDM, to eliminate malicious codes.
-
Technical Specifications
- DMR Network
- UHF:400-470MHz
- VHF:136-174MHz
- TX Power
- UHF: High power 4W/Low power 1W
- VHF: High power 5W/Low power 1W
- Public Network
- Europe &Asia-Pacific&Africa &South Korea GSM: 850/900/l BOO/l 900MHz TD-SCDMA: B34/B39 CDMA: BCO WCDMA: B1/B3/B5/B8 TDD-LTE: BJB/BJ9/B40/B41 FDD-LTE: B1/B3/B5/B7/B8/B20/B26/B27/B28 America GSM:850/900/1800/1900M Hz WCDMA:B2/84/B5 TDD-LTE:B38 FDD-IJE:B2/B3/B4/B5/B7 /Bl 2/Bl 3/817 !B’)f,M},8
- Memory
- 3GB RAM + 32GB ROM, expandable memory (maximum 128GB)
- Dimensions
- 115mm x 75mm x 21.5mm
- Weight
- 375 g (including battery, antenna, and back clip)
- Screen
- 5.0-inch HD touch screen, 1280×720 resolution
- Cameras
- Rear 13 mega-pixel camera+ front 5 mega-pixel camera
- Card Slots
- 3, 2*Nano SIM card slot, l*Micro SD card slot
- WLAN
- 2.4 GHz, 802.11 b/g/n
- Sensors
- Gravity sensor, compass, distance sensor, optical sensor
- locating
- GPS/AGPS/GLONASS/Galileo/BeiDou (shared for broadband and narrowband networks)
- Bluetooth
- BT 4.1 (shared for broadband and narrowband networks)
- NFC
- Available(Payment is not supported)
- External Interfaces
- Hytera dedicated 13-pin interface, Charging interface for charger, Antenna interface (SMA interface, shared with Td5)
- Key
- 5: l*PTT, 2*programmable key, l*alarm key, l*power key
- Battery
- Standard 2400 mAh/optional 3500 mAh, 7.4 V
- Charging Mode
- Charging with charger, 2 A charging
- Flashlight
- Available
- Volume Knob
- Available (shared with the channel knob)
