ComNav V4 High Sensitivity Thermal Night Vision and Low Light Cameras

• Gyro stabilized video images
• Uncooled high sensitivity Thermal Camera
• Light Intensifier electron tube camera
• High-sensitivity Thermal camera with digital zoom
• Objects seen through fog and smoke
• Search & Rescue, Law enforcement and Ice detection applications
• Radar slaving option
• Video on IP Output
• Crystal clear thermal images in many different color schemes
• Continuous Pan and Tilt 360° provides seamless view coverage
• 100 Hz frame rate and 1000-line resolution gives unmatched clarity
• DVI, VGA, HDMI, composite analog video output
• Marinized housing withstands the harshest conditions
• IP network control Interface capability
• 3 Axis Joystick control plus proportional Touch joystick
• 2-year warranty

Κωδικός προϊόντος: comnav v4 Κατηγορία:

Περιγραφή

THERMAL IMAGING PERFORMANCE

  • Sensor Type: Silicon CMOS Uncooled Chip,
    640 x 480 pixels, NETD < 40 mK @
    Broadband, LWIR, 30 – 100 FPS
  • Field of View: 25° (Horizontal), 19° (Vertical)
  • Focal Length: 25/35 mm
  • E Zoom: ≤ 8X
  • Image Processing: Video grabbing, recording, multi-view
    Real-time, PIP, video-analysis

DAYLIGHT IMAGING SPECIFICATIONS

  • Detector Type: Ultra low light Long range colour camera
    – Superchip II SSNR
  • Resolution: 1000-line resolution
  • Minimum Illumination: > 0.01 LUX @ colour
  • Zoom: 30 x optical zoom; 40 x digital zoom
  • FOV: 30° x 30°

SYSTEM SPECIFICATIONS

  • Video Tracking: Optional Features
  • Pan/Tilt Coverage: Ultra High Response Gyro – 360°
    Continuous Pan and tilt @ 100°/s
  • Integration Options: IP control by APP remote controller (option)
    Integration with industry standard multi-navigation
    displays optional converter interfaces
    NMEA 0183 serial communications for radar
    tracking, gyrocompass communication, etc.
    ComNav GNSS Rate Compass option

ENVIRONMENTAL

  • Operating Temp Range:-20° to 60°Celsius, ultra-strength lightweight aluminum alloy body, deep anodized surface
  • Storage Temp Range: -50° to 80° Celsius
  • Auto Window Defrost: Self-cleaning windows, w/ electron beam surface treatment

DIMENSIONS

  • Camera: 180 x 180 x 310 mm
  • Weight:4.9 kg

POWER

  • Supply Voltage: 9-24 VDC
  • Power: 50 Watt





Επιπρόσθετες Πληροφορίες

Βάρος 4,9 kg
