2 MHZ TO 30 MHZ FREQUENCY COVERAGE
2 MHz to 30 MHz frequency coverage.
EFFICIENT AND UNLIMITED CHANNELS
Efficient – tuned on each frequency and unlimited memory channels.
FREQUENCY HOPPING COMPATIBLE
Frequency Hopping compatible.
AUTOMATIC LINK ESTABLISHMENT
Fully backwards compatible 2nd generation (2G) ALE based on MIL-STD-188-141B (JITC certified) and FED-STD-1045 is available. For superior fast link setup (FLSU), robust packet data and greater penetration on noisy channels, 3rd generation (3G) ALE based on STANAG 4538 is optionally available.
- Frequency Range: 2 – 30MHz continuous
- Input Impedance: 50 ohms
- Power Rating: 150W PEP
- DC input requirements +13.8 V DC (Derived from 2000 or 4000 series transceiver via integral RF control cable)
- Power consumption Tuned Typically 400mA Tuning <800mA
- Tuning time First tune – Less than 1 seconds – typical From memory – Less than 130 mS – typical Memory addresses unlimited
- Memory addresses Unlimited
- Ingress Protection To IP67 (dust and water)
- RoHS2 Complies with Directive 2011/65/EU
- Protection Open circuit antenna, Short circuit antenna, Over temperature, High VSWR, Voltage transients
- VSWR Typically 1.5:1
- EMC Compliant
- Case construction Diecast aluminium alloy
- Colour Black
- Weight 2.4kg
