Panoptix LiveScope Plus System Garmin

Description

The latest addition to LiveScope technology, the LiveScope Plus system offers improved resolution, reduced noise, clearer images and better target separation.

GENERAL
DIMENSIONS GLS 10 SONAR BLACK BOX: 24.5 x 14.9 x 6.5 CM.
LVS32 SENSOR: 13.7 x 9.7 x 4.6 CM.
WEIGHT GLS 10 SONAR BLACK BOX: 2.0 KG;
LVS32 SENSOR: 0.9 KG
IPX7 WATERPROOF
GLS 10 BLACK BOX TEMPERATURE RANGE: -15 C TO 70 C
Panoptix LiveScope LVS32 SENSOR: 0 C TO 40 C

SONAR FUNCTIONS & SPECIFICATIONS
FREQUENCIES 530 – 1,100 kHz
MAX DEPTH BOTTOM AND FORWARD: 61.0 m

CONNECTIONS
CONNECTIONS TO GARMIN MARINE NETWORK PORT 1 (SMALL CONNECTOR)

ELECTRICAL SPECIFICATIONS
INPUT VOLTAGE 10-32 V
CONSUMPTION 21 W TYPICAL, 58 W max
POWER 500 W TRANSMITTER
RESISTANCE 7.5 A
DISTANCE FROM BOX 4″ (0.1 m)
ADDITIONAL BEAM WIDTH: 20° x 135°
SENSOR CABLE LENGTH: 6 METERS
SENSOR PIN NUMBER: 21
BEAM WIDTH: 20° x 135°
SENSOR CABLE LENGTH: 6 METERS
SENSOR PIN NUMBER: 21
