ELITE FS 7”, Lowrance

Description

THE ELITE FISHING SYSTEM  ^™

The upgraded  Multitouch  screen , combined with the  operating environment , offers a  new operating experience  and  quick access  to all device functions. Conventional  sonar , CHIRP technology  ,  DownScan  /  SideScan  and  real-time mapping  , all readily available on a device that stands out in the category of specialized tools for use in fishing.

The technology  CHIRP ( Compressed High Intensity Radar Pulse ), is the development in the fundus scanning process.

The signal transmission with CHIRP technology  , enables the collection of high quality information, resulting in a clearer and higher resolution of the seabed image. Bottom-up imaging with CHIRP  technology  offers the user  excellent segregation of targets  without losses in  greater detail .

LED Multi-touch, High Definition Screen

The devices have excellent  High Definition multi-touch screens  with high resolution to satisfy even the most demanding users. The  new flat screen  of the ELITE FS series  , works like a  smartphone  and offers a wider viewing angle,  advanced  anti-reflective coating  for perfect exposure in bright light.

Ethernet networking

For the first time, available in the Elite FS series, watertight Ethernet network port for communication and data exchange between devices. Networking adds to Lowrance’s Elite family the ability to share sonar, charts, locations, routes and other user data across screens.

Connection to external Radar module

Elite FS series devices are compatible with the Radar outdoor unit connection.
With a total of five (5) options available on an outdoor radar unit ( 3G / 4G /  Halo 20 / Halo  20+ / Halo24 ), nothing can threaten the safety of the boat (or remain hidden *)  24/32/36 / 48 Nautical miles.

* It is possible to overlap Radar points on the shipping map.

NMEA  0183 /  NMEA  2000®

Communication protocol  NMEA  0183 is  used for data exchange.

The NMEA 2000® network is   used for communication and connection of peripheral devices (audio player, bottom camera, anemometer, electronic compass, fuel sensors, etc.).
Most engine manufacturers offer a  NMEA2000®   connection kit to display all information related to engine operation (speed, operating hours, temperature, consumption, etc.).

Autopilot / Electronic Anchor

The  ELITE FS range  has specifications for connecting and operating autopilot and Electronic Anchor directly from the boat display. The autopilot system is designed for boats up to 10m long with a single or double external engine.

C Map Genesis ™ LIVE mapping

The ELITE FS range of devices   offers the ability to map the seabed in real time. With  C Map Genesis ™ LIVE , it is possible to create a personal map easily and quickly at the touch of a button while fishing.

Automatic route planning

With LOWRANCE® ‘s easy-to-use updated menu  , safe navigation is a matter of minutes. Through the navigation keys it is possible to enter starting points, stations and destination by simultaneously calculating distances of each leg of the route. It is possible to convert an executed route to a route automatically for a future repetition of the route.

* The existence of a C-MAP or Navionics shipping map is a prerequisite for the automatic routing.

Built-in high-precision GPS antenna

The built-in high-precision GPS antenna has a position correction mechanism with WAAS / EGNOS / MSAS  without the need for additional equipment.

Sonar Color Palettes

The ELITE FS series   offers 14 different color palettes in conventional sonar and 10 different palettes in bottom structure operation. Always available, the palette 13 that clearly separates the bottom with shades of brown and the targets with different colors, offering the most realistic seabed and split target depictions.

Spots, traces, routes

Up to 3,000 spots, 100 tracks and 100 tracks with 10,000 points per trace can be stored in the device’s internal memory without an additional micro SD card  .

MicroSD port

A waterproof microSD port is available for use with a detailed navigation map and unlimited bottom records for “home training”.

4 Panel split

Divide the screen into 4 parts, for more information at a glance.

Technical Characteristics  ( brief )

• Wi-Fi / Bluetooth Wireless Networking
• NMEA 2000®
Network Support • Ethernet (x1) Network Support
• ActiveTarget ™ Live Sonar
Support • Active Imaging 3-in-1 Support
• Automatic Routing || C-MAP Easy Routing || Navionics® Autorouting
• Real time mapping || C-MAP Genesis Live
• High Resolution Multi-touch Screen
• Support for FishReveal ™ Smart Target View
