SIMRAD NSS7 evo3 with world basemap

1.982,76

Το NSS7 evo3 διαθέτει οθόνη 7″ ιδανική για κεντρικές κονσόλες και άλλες εγκαταστάσεις όπου ο χώρος είναι απαραίτητος. Περιλαμβάνει παγκόσμιο βασικό χάρτη – ευρεία οθόνη SolarMAX ™ 7″

Περιγραφή

Navigate, take control, and enjoy an unprecedented level of built-in functionality with NSS evo3. SolarMAX™ HD display technology offers exceptional clarity and ultra-wide viewing angles, combined with an all-weather touchscreen and expanded keypad for total control in all conditions. Cruise confidently with ForwardScan sonar, or fish easier with StructureScan® HD imaging and dual-channel CHIRP-enabled Broadband Sounder™ technology. Built-in Wi-Fi enables access to GoFree® online services, and delivers smartphone monitoring and tablet control to extend your display’s reach well beyond the helm. The NSS7 evo3 features a 7-inch display perfect for centre consoles and other installations where space is at a premium. Includes world basemap.- 7-inch widescreen SolarMAX™ HD display

  • Reliable control in all conditions: switch seamlessly between multi-touch and a full keypad with rotary dial
  • Integrated echosounder featuring dual-channel CHIRP, ForwardScan® sonar, and StructureScan® HD imaging
  • Add StructureScan® 3D imaging, advanced Broadband Sounder™ capabilities and more via Simrad modules
  • Expand your view with Halo™ Pulse Compression radar, Broadband 3G™/4G™, and other Simrad radar solutions
  • Take complete control of Simrad autopilot systems with the NSS evo3 touchscreen or keypad
  • NMEA 2000® connectivity enables integrated engine monitoring, sound system control, and much more
  • Navigate accurately with an embedded high-gain 10 Hz GPS/GLONASS receiver
  • Enjoy easier trip planning with TripIntel™ technology and support for Navionics Autorouting/C-MAP Easy Routing (automatic routing unavailable in North America)
  • Built-in GoFree™ Wi-Fi enables online features and smartphone monitoring/tablet control
  • Choose flush-mount installation for a low-profile Glass Bridge look, or bracket-mount to install almost anywhere
  • Includes world basemap

Specifications
Dimensions 239 x 150 x 90 mm (9.4 x 5.9 x 3.5″), With bracket: 263 x 161 x 93 (10.35 x 6.31 x 3.66″)
Weight 1.1 kg (2.42 lbs.)
Enviromental Operating temperature range -15°C to +55°C (5° F to 131° F)
Environment Shock Vibration 100,000 cycles of 20G
Storage temperature range -20°C to +60°C (4°F to 140°F)
Water resitance IPX6 and 7

Power
Supply voltage 10 – 31.2 V DC
Fuse rating 3A
Power consumption (Max) 20W

Display
Display backlight color White
Display resolution 600 x 1024
Display screen brightness 1200 nits
Display sizeand type High Visibility SolarMax HD® IPS 7″ optically bonded TFT
Display viewing angles 80° top/bottom, 80° left/right

Connectivity
None

Ethernet 1 x 5 pin yellow connector x 1 Mbit, max 6 processors on network
Bluetooth Internal
NMEA2000 connectivity 1 x NMEA 2000 Micro-C port, 1 LEN
NMEA 2000 PGNs Receive only
